eDragon 1000 Feet Cat6e (CMR) UTP 23AWG, Solid Bare Copper, 550MHz, UL Certified, Easy to Pull Box, Bulk Ethernet Cable…

Description

Overview

Cat6e (CMR) bulk cable is 1000ft, 4 Pair, Unshielded Twisted Pairs (UTP), 23AWG, Solid Bare Copper Conductors for optimal signal strength. Top rated performance with 3-5 dB extra margin over EIA/ TIA-568.2-D standards. Highest for installations in your house and business, installs, in walls, between flooring and can also be substituted for CM rated applications. Run this Cat6e unshielded cable as much as 328 Feet (100 meters). Easily connect this cable with unshielded Cat6 connectivity such as keystone jacks, RJ45’s and field termination plugs.

Features:
• UTP CABLE CAT6, #23 AWG X 4 PAIR W/HDPE INSULATION
• AND FLAME-RETARDANT PVC JACKET
• UL Listed Type CMR
• C(UL) listed CMG FT4
• ETL Listed Type CMR
• C(ETL) listed CMG FT4
• TIA/EIA-568-C.2, UL 1666 CMR RATED
• IEC 61156 AND ANSI/TIA-568-C.2
• ROHS Compliant
• ATM 155 Mbps
• Ethernet 10BASE-T, 100BASE-TX, 100BASE-VG, 100BASE-T4
• 1000 Mbps 1000BASE-T Gigabit Ethernet™ (IEEE 802.3)
• 16 Mbps Token Ring™ (IEEE 802.5)

Specifiaction:
Number of Conductor Pairs:- 4
Size:- 23 AWG
Stranding:- Solid
Conductor Material:- Solid Annealed Bare Copper
Shield Material:- Unshielded
Rip Cord:- Yes
Insulation Material:- Polyethylene
Insulation Overall Diameter:- 0.040 in. ± 0.0002 in
Insulation Average Thickness:- 0.0088 in
Jacket:- Flame Retardant PVC
Voltage Rating:- 300V
Outer Jacket Average Wall Thickness:- 0.023 in.
Outer Jacket Nominal O.D:- 0.244 in. ± 0.008 in.

Ensure that this fits by entering your model number.
HIGH PERFORMANCE NETWORK CABLE: This rated cat 6e lan cable is 23 AWG with 4 pairs. Bandwidth tested as much as 550 MHz. Supports1000 Mbps 1000BASE-T Gigabit Ethernet (IEEE 802.3af/at/bt) as much as 60W and 300V DC.
100% CERTIFIED SOLID BARE COPPER CONDUCTOR: It’s time to fail to remember Copper Clad Aluminum cables (CCA) – With a higher conductivity and tensile strength, fast Cat. 23AWG Solid Copper Conductors transmit faster even as lasting the distance. For heavy traffic networks, and as a great gaming ethernet cable – it just makes Highest sense
REDUCED CROSSTALK: Four twisted pairs with a PVC Cross Separator reduces noise for clean uninterrupted connection. This cross flexi-core makes for a more durable cable that won’t bend or break.
THE PERFECT: Cat6E CMR cable to your high speed applications. Suitable for 1Gig and 10Gigabit. This cable is 23 AWG, Solid Conductors, pure bare copper, and is utp (unshielded twisted pairs). Connect with RJ45’s and Keystone jacks to build your network.
Cat6E CMR cable is great for in wall, riser areas, computers, POE, switches, ethernet ports, gaming systems, VoIP, Routers, IP Cameras, hubs and plenty of more!
